3.05 Melody On Off ================== - Dependent on meteorological data a voice is set on or off. - This is handy for a meteorological parameter like global radiation. At night there is no global radiation and therefore it is zero. To prevent that the same tone is repeated over and over again the voice can be paused. - Weather period from the 1.8.2019 to 28.8.2019 .. code:: python3 from pyknon.genmidi import Midi from pyknon.music import Rest, Note, NoteSeq from music_generation import* import numpy as np import pandas as pd import matplotlib.pyplot as plt import matplotlib.ticker as plticker from datetime import date Read Meteorological Data ~~~~~~~~~~~~~~~~~~~~~~~~ .. code:: python3 def read_meteo_data(fName): colNames = ['Stao','time', 'T_Boden_20cm', 'Flash_30km', 'Glob_rad', 'QFE','T_2m','Rain_Sum','H_rel','visibi','V_wind','direction_wind'] df = pd.read_csv(fName,sep=';', skiprows=3, names=colNames, na_values='-') print(df.head()) return df fPath = '/mnt/daten/04_Schule/42_Kanti/Matrua/Music_generation/Organisation/MeteoSchweiz/Daten/' fName = 'order_75330_data.txt' dM = read_meteo_data(fPath+fName) NT, MP = dM.shape .. parsed-literal:: Stao time T_Boden_20cm Flash_30km Glob_rad QFE T_2m \ 0 KLO 201908010000 21.5 0 2 969.5 15.3 1 KLO 201908010010 21.5 0 2 969.5 14.9 2 KLO 201908010020 21.5 0 2 969.5 14.6 3 KLO 201908010030 21.5 0 2 969.5 14.6 4 KLO 201908010040 21.4 0 2 969.6 13.7 Rain_Sum H_rel visibi V_wind direction_wind 0 0.0 80.4 20000.0 0.9 117 1 0.0 82.4 20000.0 1.1 98 2 0.0 83.7 20000.0 1.0 121 3 0.0 82.7 20000.0 1.2 119 4 0.0 88.8 20000.0 1.0 173 Chords and scales ~~~~~~~~~~~~~~~~~ .. code:: python3 C = np.array([ 0, 4, 7]) Cm = np.array([ 0, 3, 7]) Cdim = np.array([ 0, 3, 6]) CM7 = np.array([ 0, 4, 7, 11]) C7 = np.array([ 0, 4, 7, 10]) Cm7 = np.array([ 0, 3, 7, 10]) Cdim7 = np.array([ 0, 3, 6, 10]) Cdim6 = np.array([ 0, 3, 6, 9 ]) C6 = np.array([ 0, 4, 7, 9 ]) # inversion of Am7 Cm6 = np.array([ 0, 3, 7, 9 ]) Csus4 = np.array([ 0, 5, 7]) Csus2 = np.array([ 0, 2, 7]) Csus47= np.array([ 0, 5, 7, 10]) P = np.array([ 0,7]) # Power chord (Perfect unison, Perfect fifth) B = np.array([ 0]) # Bass (Perfect unison) major = np.array([ 0, 2, 4, 5, 7, 9, 11]) minor = np.array([ 0, 2, 3, 5, 7, 8, 10]) blues = np.array([ 0, 3, 5, 6, 7, 10]) on\_off ~~~~~~~ - Mutes and unmutes voices dependent of the meteorological input data. - With on\_range defines when a voice plays. - on\_off is applied after the met\_transform. So the on\_range must be adjusted accordingly. .. code:: python3 def on_off(meteo, on_range, volumes, rythem, mpb): met_resolution = 10 cum_ryth = np.concatenate((np.asarray([0]),np.cumsum(rythem)))[:-1] # add 0 at beginig remove last element i_data = (cum_ryth*4 * (mpb /met_resolution)).astype(int) # calculate index of the data for npn in range(len(i_data)): value = meteo[ i_data[npn] ] # get value of the meteo data if on_range[0] < value < on_range[1]: pass # do nothing when in on_range else: volumes[npn] = 0 # set volume to zero when out of range return volumes tune 305\_A ----------- - Period from the 11.8 to 15.8.2019. - Temperature and pressure played by pianos. - Timpani regulated by the rain. - A Music box plays the melody of the global radiation. During night the melody is paused. .. code:: python3 def tune_305_A(): tune_name = 'tune_305_A' np.random.seed(80) bar, bpb = 20, 4 # bar: Takt , bpb: beat per bar s_day, s_hour = 10, 12 # Start point in the data mpb = 80 # minutes per beat end_dur = 0 melody_len, start = print_dur(bar,bpb,mpb,s_day,s_hour,tune_name) trans = met_transform(dM,[1,1,0.025,3,1.3,500,0.2,1,4.5,1,],[6,6,6,6,6,24,6,6,6,2],start) scales = [[8,'C',major]] end_scale = [[1,'C',P]] pattern = pattern_gen(scales, end_scale, melody_len) # Pressure rythem1, notenr_1 = ran_duration([1/32,1/8, 1/4,1/2], [0,2,3,1], melody_len, end_dur) melody1 = meteo_melody(trans[3],pattern, 42, notenr_1, rythem1,mpb) volumes1 = ran_volume([0,90], [1,8], notenr_1 ) notes1 = NoteSeq( [Note(no,octave=0, dur=du, volume=vo) for no,du,vo in zip(melody1,rythem1,volumes1)] ) # temp rythem2, notenr_2 = ran_duration([1/16,1/8, 1/4,1/2], [0,2,3,2], melody_len, end_dur) melody2 = meteo_melody(trans[4],pattern, 80, notenr_2, rythem2,mpb) volumes2 = ran_volume([0,90], [1,8], notenr_2 ) notes2 = NoteSeq( [Note(no,octave=0, dur=du, volume=vo) for no,du,vo in zip(melody2,rythem2,volumes2)] ) #timpani rain melody3, rythem3, volumes3 = drum([1/16], [60,63],[100,127],melody_len) volumes3 = met_vol(trans[5],0,rythem3, mpb) notes3 = NoteSeq( [Note(no,octave=0, dur=du, volume=vo) for no,du,vo in zip(melody3,rythem3,volumes3)] ) # glob radation rythem4, notenr_4 = ran_duration([1/32,1/16,1/8, 1/4,], [0,3,1,0], melody_len, end_dur) melody4 = meteo_melody(trans[2],pattern, 90, notenr_4, rythem4, mpb) volumes4 = ran_volume([0,80], [0,8], notenr_4 ) volumes4 = on_off(trans[2],[5,20000],volumes4, rythem4, mpb) notes4 = NoteSeq( [Note(no,octave=0, dur=du, volume=vo) for no,du,vo in zip(melody4,rythem4,volumes4)] ) instruments = [0,0,47,10] notes = [notes1,notes2,notes3,notes4] return notes, instruments,tune_name .. raw:: html
tune_305_A
tune_305_A


**Instruments:** Available are at lest the 128 General-Midi (GM) Instruments. Depending on the sound-fonts there is a bigger choice. A list of the GM instruments can be found here. https://jazz-soft.net/demo/GeneralMidi.html Generate Midi and Audio file ---------------------------- .. code:: python3 def gen_midi(): # squezze into a MIDI framework notes, instruments, tune_name = tune_305_A() # <--- select a tune <<-- <<<<<<<<<--- select a tune ----- nTracks = len(notes) m = Midi(number_tracks=nTracks, tempo=120, instrument=instruments) for iTrack in range(nTracks): m.seq_notes(notes[iTrack], track=iTrack) #--- write the MIDI file ----- midi_file_name = tune_name +'.mid' # set the name of the file m.write(midi_file_name) return midi_file_name .. code:: python3 ######--- Main ---###### midi_file_name = gen_midi() midi_play(midi_file_name) midi_audio(midi_file_name) midi_png(midi_file_name) .. parsed-literal:: tune_305_A: Start: 10 day 12 h End: 14.0 day 22.666666666666686 h .. image:: output_14_1.png External **Music\_Generation** library ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ This library changes from version to version. New or changed code is first explained above. This is a copy of music\_generation.py .. literalinclude:: music_generation.py :language: python
